Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope

Products - Digital LCD Microscope
  • Highlight

    digital usb microscope

    ,

    portable digital microscope

  • LCD Screen
    11.6''
  • Objective
    0.7-4.5x Zoom Objective, Zoom Ratio 6.4:1
  • Magnification
    17x-110x
  • Working Distance
    100mm
  • Camera Sensor
    1/2" COMS
  • Resolution
    1920*1080p
  • Transmission Rate
    60FPS 2.0M
  • Light Source
    LED Ring Light, With Switch On/Off, Brightness Adjustable.
  • Output
    HDMI,USB,TF
  • Power
    External Wide Range Adapter
  • Place of Origin
    China
  • Brand Name
    CNOEC, OPTO-EDU
  • Certification
    CE,
  • Model Number
    A36.3601
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1 pc
  • Price
    FOB $1~1000, Depend on Order Quantity
  • Packaging Details
    Carton Packing, For Export Transportation
  • Delivery Time
    5~20 Days
  • Payment Terms
    T/T, West Union, Paypal
  • Supply Ability
    5000 pcs/ Month

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope

  • Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope
  • Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope
  • Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope
  • Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope
  • Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope
Get Price Contact Now
Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 0

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 1

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 2

A36.3601 LCD stereo microscope

The A36.3601 series integrated zoom optical module with high definition camera. It can be conveniently used in a narrow and small space. According to ergonomic principles, its internal optical corner design and angle adjustment of the display screen, allow the operator to look at the display in a flat view. Through the HDMI HD interface, it can connect to another display simultaneously.

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 3

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 4
A36.3601 LCD Digital Stereo Microscope Specification
Magnification 17X-110X
Objectives 0.75X-4.5X stereo zoom, zoom ratio 6.4:1
Display 11.6Inch, 1920H*1080V, IPS screen, detachable
Imaging sensor 1/2.8Inch SONY CMOS
Real-time image frame rate 60fps@1920*1080
Photograph 5 Mega-pixel
Recording 45fps@1920*1080
Output Interface HDMI
Input Interface Double USB2.0
Camera Parameters Exposure, White-balance, Gain, Gamma, Brightness, Contrast, Hue, Saturation, Gray
OSD Operation Mouse
Storage Function Snap, Record, USB Storage
Measurement Point,Line,Parallel lines,Broken lines,Angle,Diameter circle,Radius circle,Three-point circle,Distance from circle to line,Concentric circles,Double circle,Vertical line,Arbitrary line,Polygon,Arc,Mark,Screenshot,Table data export,Calibration,Parameter Settings
Other Functions Flip horizontally, Flip vertically, Freeze
Scale Ruler 3 kinds, customizable colors, line widths, display switches
Grid Lines 8 group, customizable colors, line widths, display switches
Languages Simplified Chinese,Traditional Chinese,English,French,Russian,Japanese,Italian,German
Auxiliary Lens 0.5x
2.0x
Light Source 56-LED ring light, brightness adjustable
Base Various bases are available according to customers' requirements
Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 5

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 6

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 7
A36.3601 LCD Digital Stereo Microscope Optical Data Sheet
Objective Standard Auxiliary 0.5X Auxiliary 2X
W,D. 100mm 165mm 30mm
11.6‘’ Mag View Field Mag View Field Mag View Field
17.2x-110.5x 18.5x10.5-2.8x1.5 8.6x-55.2x 37.5x21-5.5x3.0 34.4x-221x 9.5x5.5-1.5x0.7

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 8

Stereo Electron Measurement 0.7-4.5x Zoom LED LCD Digital Microscope 9
