Trinocular Five Wave Fluorescence Microscope With Fine Focus A16.1101
Specifications:
|
A16.1101 Five Wave fluorescence microscope Specification |
|
Viewing head
|
Compensation Free trinocular Head, at 30°, 360° Rotatable, interpupillary 50-75mm |
|
Eyepiece
|
Hight point and extra Wide Field WF10X/ FN22, eyepiece tube Dia:30mm |
|
WF10X/20 Crosee reticle eyepiece with scale:0.1mm |
|
Nosepiece
|
Backward Sextuple Nosepiece |
|
lnfinity Apochromatic Fluorescent Objective
|
4X/NA0.15 |
|
10X/NA0.35 |
|
20X/NA0.6 |
|
40X/NA0.75 |
|
Stage
|
Double Layers Mechanical Stage 180x160mm, Moving Range 80x50mm |
|
Condenser
|
Abbe Condenser N.A.1.25 with Iris Diaphragm and filter |
|
Focusing
|
Coaxial Coarse & Fine Focus Adjustment with Rack and Pinion Mechanisn,Fine Focusing Scale Value0.002mm |
|
Transmitted Illumination
|
Halogen Bulb 12/30w |
|
Epi-fluorescent attachment |
as following |
|
Reflected Light
|
|
Excitation
|
Dichroic Mirro
|
Barrier filter
|
|
B(Blue)excitation filter system |
EX450-490
|
DM505
|
BA520
|
|
G(Green)excitation filter system |
EX510-560
|
DM575
|
BA590
|
|
U(Ultraviolet) excitation filter system |
EX330-380
|
DM400
|
BA420
|
|
V(Violet) excitation filter system |
EX380-420
|
DM430
|
BA450
|
|
BV(Blue and Violet) excitation filter system |
EX400-440
|
DM455
|
BA470
|
|
Y(Yellow) excitation filter system--(Opitonal) |
EX540-580
|
DM595
|
BA600
|
|
Protection Barrier |
Barrier to resist the Ultraviolet light |
|
Lamp |
100WHBO Ultra Hi-voltage Spherical Mercury Lamp |
|
Protection Barrier |
Barrier to Resist the Ulraviolet Light |
|
Power Supplier |
Digital Display |
|
|
|
Optional Accessory
|
|
Eyepiece |
WF16X/17 |
|
WF20X/12.5 |
|
Objective |
Infinity Plan Achromatic Objective 4x |
|
Infinity Plan Achromatic Objective 10x |
|
Infinity Plan Achromatic Objective 20x |
|
Infinity Plan Achromatic Objective 40x(s) |
|
Infinity Plan Achromatic Objective60x(s) |
|
Infinity Plan Achromatic Objective100x(S)oil |
|
Fluorescent Objective |
Infinity Achromatic Fluorescent 100x (Dry) N.A.0.9 |
|
Y Wave band Fluorescent box |
EX540-580 DM595 BA600 |
|
CCD adapter |
0.5x CCD adapter
|
|
0.57x CCD adapter |
|
0.75x CCD adapter |
|
